| Model | RSM-WCS-8150 |
| Display Way | 7 inch HMI |
| Function | Cable cutting & stripping |
| Cable Type | PVC cable，sheath cable |
| Capacity Range | 1-30mm² |
| Cutting Length | 1mm-99999.99mm |
| Cutting Tolerance | Within 0.002xL（L=Cutting Length) |
| Stripping Length | Front End：1-180mm |
| Rear End：1-400mm |
| Guiding Tube I.D. | Φ33 |
| Productivity | 1800pcs/h（Depending on the length of the line,depending on the size） |
| Dynamic Source | Servo motor（whole machine） |
| Feeding Way | Conveyor belt,no imprint and scratch cable,32wheel drive |
| Power | 220V/50HZ±10% |
| Installed Capacity | 5.2KW |
| Full Load Current | 30A（Allow to Min.Current 18A） |
| Air Source | 0.5-0.8Mpa clean air source |
| Special Function 1 | Machine can be customized base on the sample if the cable is unique |
| Special Function 2 | Stripping and crimping insulation,full stripping front end,encode machine |
| Miscellaneous Function | Material collected gripper,Material collected manipulator,wire collected rack(Module insulation should be added when using it) |
| Net Size | L900mm*W610mm*H1150mm |
| Packing Dimension | L1000mm*W760mm*H1340mm |
