Wire Processing Center (Single End) RSM-WPC-800

Compact design with comprehensive functions, minimal footprint.
Windows Operating System. Make it easy to integrate visual system, CFM and other future automation technologies.
High precision and fast speed guaranteed by hybrid servo drive and motion control system.
Up to 100 set of processing recipes are available, which facilitate quick processing of different wires.
Quick and easier changeover of cutter with a clamping mechanism to save labor.
Automatic reset of wire twisting mechanism, no need to adjust parameters when processing different wires.
Easier troubleshooting with indicator lights for abnormal signals on built-in circuitry.

Specification


Model	RSM-WPC-800
Function	wire cutting, stripping, terminal crimping, twisting&tinning (single end), housing insertion
Wire O.D.	AWG#32-AWG#16
Cutting Length	55mm-800mm
Stripping Length	0.1mm-7mm
Twisting Length	3mm-8mm
Crimping Force	2.0 Ton
Crimp Position Adjusting	Adjustment via HMI
Detection	CFM/A, CCD visual inspection
Productivity	1200~2000pcs per hour
Air Source	5-7kgf (clean and dry air)
Power	5KW
Voltage	AC220V 50/60HZ (single phase)
Weight	1428kg (G.W.)
Dimension	L1750mmW1450mmH1700mm
